FARO DELANTERO LED HIGHSIDER HD-STYLE TIPO 2 (MONTAJE INFERIOR)

HIGHSIDER LED HEADLAMP HD-STYLE TYPE 2, 7 INCH

HIGHSIDER 7 inch LED spotlight HD-STYLE TYPE 2 for lower mountingStylish-innovative power LED spotlight in a puristic design with parking light function and a round, clear glass. The oval, satin matt black or chrome metal housing has a black or chrome-plated, asymmetrical - for right-hand traffic only - insert, e-approved.The bright joy - give your bike an unmistakable style! The unusual design and the perfect technology of the HIGHSIDER headlight series make it a highlight in any case!Dimensions:Housing diameter: 220 mmHeadlamp insert diameter: 178 mm Depth: 155 mmDistance between mounting holes on holder (centre - centre): 65 mmPower consumption at 12.5 volts DC:Low beam: approx. 1.6 Ampere (20 Watt), 12 Volt 1450 LumenOnly the upper reflector and the middle ellipsoid insert are illuminated.High beam: approx. 1.6 Ampere (20 Watt), 12 Volt 1582 LumenOnly the upper and lower reflector is illuminated. The middle ellipsoid insert also stops when the headlight flashes.Connections on the reflector in the headlight housingThe following 3 cables end in a combination plug:Black cable = ground (-)Red cable = high beam (+)Blue cable = low beam (+)Additional 2 cables for parking light: Black = Ground (-), Red = parking light (+)White= Connection for control indicator (can be used optionally)Scope of delivery: 1 piece including mating plug (connecting plug) with 210 mm cable, for H4 halogen bulbs, connections:Green cable = ground (-)Blue cable = high beam (+) White cable = low beam (+)Instructions for use asymmetrical, approved for right-hand traffic only:Use asymmetrical, only permitted for right-hand traffic.
